Autel EVO Lite Enterprise Series tutorials are here! For those who have previously purchased the Autel EVO Lite series and are eager to try the new enterprise drone features of the Autel EVO Lite Enterprise series, or have purchased an EVO Lite Enterprise drone but haven't flown it yet? Let us help you smoothly transition from consumer to enterprise user and grow together!

A Review of the Autel EVO Lite Series

The Autel EVO Lite series is consumer-oriented, consisting of two drones: EVO Lite and EVO Lite+. Weighing approximately 835g, they require FAA registration and are available in orange, gray, and white. The maximum flight time is 40 minutes. The EVO Lite supports portrait 4K shooting, while the EVO Lite+ supports 6K@30fps shooting.

Understanding the Autel EVO Lite Enterprise Series

The Autel EVO Lite Enterprise series is consumer-oriented and includes two drones: the EVO Lite 6K Enterprise and the EVO Lite 640T Enterprise. Weighing approximately 866g, these drones require FAA registration, are only available in gray, and have a maximum flight time of 40 minutes. They are among the lightest and most portable foldable commercial drones on the market.

The EVO Lite Enterprise series comes with the Autel Smart Controller SE V2, supporting AI recognition, intelligent planning, and live video streaming. The EVO Lite 6K Enterprise supports 6K@30fps recording, while the EVO Lite 640T Enterprise supports a 640*512 thermal camera.

Common Issues for Beginners When Using the EVO Lite Enterprise Series

Pairing Issues

The EVO Lite Enterprise series uses the Autel Smart Controller SE, which includes the Autel Enterprise App for managing drone flight, photography, and work tasks.

Choosing the EVO Lite Enterprise series drone kit eliminates the need to download a flight app on your phone, allowing for quick pairing and takeoff. However, during pairing, ensure both the drone and remote controller are updated to the latest versions for successful pairing.

AI Recognition Function

With the EVO Lite Enterprise series drone, whether using the Zoom camera interface, IR camera interface, or split-screen display, the aircraft can automatically recognize and locate objects, including people, cars, and boats, and project their positions onto a map.

However, the recognition function and accuracy depend on the drone's flight state (hovering, flying) and current altitude. Generally, hovering and lower altitudes are more conducive to recognition and location.

Obstacle Avoidance Function

The EVO Lite Enterprise series drone features six visual sensors and intelligent algorithms, enabling accurate obstacle recognition and braking/hovering. Obstacle avoidance is automatically activated and requires no manual intervention.

Flight Missions

The Autel EVO Lite Enterprise series supports Rectangle, Waypoint, Polygon, Record, and Import flight missions, and also supports offline maps, further enhancing your intelligent flight experience. Please note that you cannot simultaneously enable photo taking and video recording while your smart task is in progress.

Live Streaming Function

The EVO Lite Enterprise series drones support adaptive frequency hopping at 2.4GHz/5.2GHz/5.8GHz, enabling real-time transmission of 1080P/30FPS high-definition images.

Since the Autel Smart Controller SE V2 lacks an HDMI port, it is recommended to purchase the Autel Smart Controller SE and Autel Smart Controller V3 remote controller, which support remote real-time streaming via HDMI/RTMP and GB28181 protocols.

The Autel Smart Controller SE supports the installation of third-party Android applications, allowing you to try third-party live streaming output. However, the signal connection is not as stable as a wired connection.

Encrypted Storage

When using the Autel EVO Lite Enterprise series drones, photos, videos, and flight logs are encrypted with AES and require a password for access, enhancing data privacy. The Smart Controller SE V2 remote controller has 32GB of built-in storage and supports up to 128GB microSD card expansion.

Post-Processing

The EVO Lite Enterprise series focuses on industrial applications. Unlike the Autel Sky App included with the EVO Lite series, which supports cinematic shots, adds background music, filters, and templates, and allows for one-click sharing, you'll need to back up your footage from the SD card to your computer and then use professional video editing software to output the video you want.

Thermal Imaging Processing

The Autel Smart Controller SE V2 features a clean interface, allowing you to quickly switch thermal imaging perspectives. The Autel EVO Lite 640T Enterprise drone provides precise temperature measurement distances from 1 to 25 meters. Heat source identification is integrated into target identification and positioning, and it offers switchable White Hot/Black Hot/Searing/Rainbow/Grey/Ironbow/Cold and Hot perspectives, providing accurate aerial situational awareness for applications such as law enforcement, security patrols, emergency rescue, and nighttime livestock management.

Drone Maintenance

The Autel EVO Lite Enterprise series is compact and lightweight. After exploring commercial drone projects to make money, you'll also need to properly maintain the drone and its remote controller. Avoid flying in harsh environments, prepare landing pads for drones during takeoff and landing, protect drone lenses, manage batteries properly, and comply with flight regulations and local policies.

Summary

When shifting your focus from consumer drones to enterprise drones, you might feel overwhelmed because many aspects are unclear. However, the Autel EVO Lite Enterprise is a great entry-level enterprise drone for beginners. It's lightweight and compact, has a user-friendly interface, customizable toolbars, multiple flight missions to choose from, and is compatible with EVO Lite series accessories. The EVO Lite 640T Enterprise, even a thermal imaging drone priced around $3000, offers excellent value.

Choosing the Autel EVO Lite Enterprise series drones is the best way for enterprise drone users to understand the fundamentals of commercial drones!
