The EVO MAX 4N drone has undergone a major upgrade, focusing on camera specifications and drone performance. The Autel EVO MAX series is one of the benchmarks for commercial drone autonomy. Let's take a look at the powerful performance of the upgraded version of the EVO MAX 4N drone, the EVO MAX 4NZ V2!
What is the EVO MAX 4N drone？
The Autel EVO Max 4N drone is a high-end industrial/public security/night flight/inspection drone from Autel, featuring night vision capabilities, integrated sensing, and autonomous flight capabilities.
What is the EVO MAX 4NZ V2 drone？
The Autel EVO MAX 4N V2 vs. the Autel EVO MAX 4N only upgrades the drone's body performance; the camera payload remains unchanged. The Autel EVO MAX 4NZ V2 vs. the Autel EVO MAX 4N not only improves the drone's body performance but also further enhances its night vision capabilities!
Autel MAX 4NZ V2 Drone Specifications
-
Maximum Flight Time: 42 minutes
-
Camera System: Equipped with a Fusion 4NZ-L gimbal module, it integrates a telephoto night vision camera, a wide-angle night vision camera, a thermal imaging camera, and a laser rangefinder (5–1200 m range).
-
Night/Low-Light Performance: Featuring "Starlight Vision" and superior zoom capabilities, it is not limited by ambient light or temperature differences, enabling target identification in extremely low-light environments.
-
Transmission/Communication: Image and control links have a maximum transmission distance of ~15 km.
-
Anti-Interference/Perception System: Utilizes multi-sensor fusion (binocular + millimeter-wave radar) for all-round obstacle avoidance and environmental awareness.
-
Networking/Collaboration: Supports A-Mesh networking, enabling multi-robot collaboration and communication relay.
- Environmental Adaptability & Enclosure Rating: Dust and water resistant to IP43 (customizable), operating within a temperature range of -20°C to +50°C / -4°F to +122°F.
-
Weight/Takeoff Weight: Aircraft weight (battery and gimbal included) is approximately 1,715 g. Maximum takeoff weight (including payload) is approximately 1,999 g.
- Maximum Speed/Wind Resistance: The aircraft can reach a horizontal flight speed of approximately 82.7 km/h (approximately 23 m/s) and can withstand winds of approximately 27 mph (approximately 12 m/s).
Camera: Fusion 4N vs. Fusion 4N V2 VS Fusion 4NZ V2
The EVO MAX 4NZ V2 boasts all the features of the existing EVO MAX series drones and is a new member of the EVO MAX series. Therefore, we will focus on the differences between the EVO MAX 4NZ V2 and the camera gimbal.
| Fusion 4N | Fusion 4N V2 | Fusion 4NZ V2 | |
 |
 |
 |
|
| Super-Starlight Night Vision Camera | 2.3MP LUX:0.0001 ISO: 450000 Equivalent: 41.4mm |
2.3MP |
/ |
| Telephoto Night Vision Camera |
/ |
/ |
1/1.2-inch CMOS 8MP 2.61-16x Digital Zoom 147.3 mm Equivalent Focal Length ISO: 100-100000 Max. Vide0 Resolution: 3840×2160@30fps Photo Size: 3840X2160 |
| Wide-Angle Night Vision Camera |
/ |
/ |
1/1.2-inch CMOS 8MP 1-2.6x Digital Zoom 53.9 mm Equivalent Focal Length ISO: 100-100000 Max. Vide0 Resolution: 3840×2160@30fps Photo Size: 3840 X2160 |
| Super-Sensitive Wide-Angle Camera |
50MP |
50MP |
/ |
| Thermal Camera |
640x512 |
640x512 |
640x512 |
| Laser Rangefinder |
Measuring Range: 5-1200m(16.4-3737 ft) |
Measuring Range: 5-1200m(16.4-3737 ft) |
Measuring Range: 5-1200m(16.4-3737 ft) |
| Infrared Laser Fill Light¹ |
/ |
/ |
8°Field Angle |
| Infrared Laser Fill Light² |
/ |
/ |
30°Field Angle |
The Autel EVO MAX 4NZ V2 drone boasts powerful performance, unmatched among night vision drones! Its night vision starlight camera enhances zoom capabilities and wide-angle shooting. Even in low light conditions, the dual built-in fill lights of the Fusion 4NZ-L camera provide excellent nighttime image clarity. Combined with a thermal imaging camera, the EVO MAX 4NZ V2 night vision drone is a top-tier drone for nighttime operations.
