Autel Alpha VS Autel Titan VS Autel MAX 4T/4N

Autel Alpha VS Autel Titan VS Autel MAX 4T/4N

Autel Robotics has developed a new generation of industrial drones, and here we compare the best Autel commercial drones. Autel Alpha VS Autel Titan VS Autel MAX 4T/4N, we will quickly take a look at the specifications and features of these drones.

Autel Alpha drone and Autel MAX 4T both have powerful zoom functions. Autel EVO MAX 4N drone uses a starlight camera, which can support shooting everything at night. Autel Titan drone is highlighted by its powerful carrying capacity, with a maximum Supports 10kg load.

Product Comparison: Autel Titan vs Alpha vs EVO MAX 4T/4N

Comparison Items Autel Titan Autel Alpha Evo Max (4N/4T)
Dimensions

1879×1866×584 mm (unfolded with propellers)
1141×1120×563 mm (unfolded without propellers)
745×470×335 mm (folded without propellers)

1206×982×272 mm (unfolded with propellers)
780×568×272 mm (unfolded without propellers)
454×266×255 mm (folded without propellers)

562*651*147mm (unfolded with propellers)
318*400*147mm (unfolded without propellers)
257*145*131mm (folded without propellers)

Total Weight 24300g 6100g 1999g
Maximum Takeoff Weight 31000g 8100g 1999g
Wheelbase 1447mm 813mm 466mm
Maximum Horizontal Flight Speed 25 m/s 23 m/s 23 m/s
Maximum Flight Time 60min 48min 42min
Maximum Wind Resistance 12 m/s (for takeoff and landing) 12 m/s (for takeoff and landing) 12 m/s (for takeoff and landing)
Maximum Flight Altitude 4500m

4500m
7000m (with high-altitude propellers)

4000m
IP Protection Level IP55 IP55 IP43
Obstacle Avoidance System Vision obstacle avoidance (fisheye lens) + 6-direction millimeter-wave radar 5-directional visual obstacle avoidance (10 fisheye lenses)+6-directional millimeter-wave radar

5-directional visual obstacle avoidance (10 fisheye lenses)+4-directional millimeter-wave radar

Payload Expansion Interface

Bottom camera interface *1
Left and right sides: PSDK interface ×3
OSDK interface ×1 (to be confirmed)

camera interface*1
Type-C interface*1

One of the advantages of Autel Titan drones and Autel Alpha drones compared to the EVO MAX series is the addition of the more powerful gimbal camera Autel L35T. We will further compare the specifications and features of Autel Alpha drones, Autel Titan drones and EVO MAX series drones.

Gimbal Camera Comparison: Autel L35T vs Fusion 4T/4N

Comparison Items Autel L35T Camera Fusion Camera 4T Fusion Camera 4N
Gimbal Camera Appearance
Autel L35T Gimbal Camera

Autel MAX 4T Gimbal Camera
 Autel L35T Gimbal Camera
Zoom Camera

1/1.8" CMOS 35x optical zoom Focal length: 7.1 ~ 171.95 mm 8 million effective pixels

1/2" CMOS 10x optical zoom Focal length: 11.8-43.3mm 48 million effective pixels

/
Wide-Angle Camera /

1/1.28" CMOS 50 million DFOV: 85°

1/1.28" CMOS 50 million DFOV: 85°

Night Vision Wide-Angle Camera

1/2" CMOS 48 million pixels Aperture: f/2.8 DFOV: 84°

/ Recognizable at a minimum brightness of 0.001 lux ISO 100~ISO 450000
Infrared Thermal Imaging Wide-Angle Camera

Focal length: 13mm FOV: 42° 640*512/30fps

Focal length: 13mm FOV: 42° 640*512/30fps

Focal length: 9.1mm FOV: 42° 640*512/30fps

Infrared Thermal Imaging Telephoto Camera

Focal length: 45mm FOV: 12.3° 640*512/30fps

/ /
Laser Rangefinder

Range: 10 ~ 2000 meters Accuracy: Under 400m: +1m; Above 400m: (D*0.3%)

Range: 5 ~ 2000 meters Accuracy: ± (1m + D×0.15%)

Range: 5 ~ 2000 meters Accuracy: ± (1m + D×0.15%)

Summary 1. Master of integration: The L35T integrates night vision wide-angle, zoom, telephoto infrared, short-focus infrared, and laser rangefinder, meeting the usage needs in various environments.
