Autel EVO II 640T Enterprise V3 Visible Camera Specifications

Due to ongoing global supply chain disruptions and shortages of key chips in the electronics industry, the EVO II V2 series has been fully upgraded to the EVO II V3 series. The upgrade to the Autel EVO II Dual 640T Enterprise includes two visible camera models.

Here, we will focus on these two visible camera models.

Autel 640T V3 Series Visible Camera Specifications Comparison

	EVO Il Dual 640T Enterprise - Visual camera①	EVO Il Dual 640T Enterprise - Visual camera②
Image sensor	1/1.28 inch CMOS, 50 million pixels	1/2 inch CMOS, 12 million pixels
Lens	Field of view: 85° 35 mm format equivalent focal length: 23 mm Aperture: f/1.9 Focus distance: 0.5 meter ~ ∞	DFOV: 84° Effective Focal Length: 7 mm 35mm Equivalent Focal Length: 24 mm Aperture: F2.8 AF Type: FF Manual Focus Distance: 1.5 m ~ ∞ (Fixed Focus)
ISO range	Video: ISO100 ~ ISO6400 Photo: ISO100 ~ ISO6400	Video: ISO100 ~ ISO6400 Photo: ISO100 ~ ISO6400
Shutter speed	Photo mode: 1/8000 ~ 8 seconds Others: 1/8000 ~ 1/30 second	Photo: 0.5s ~ 1/8000s Video: 1/30s ~ 1/8000s
Zoom	1 - 16x digital zoom (maximum 4x lossless zoom)	1 - 16x digital zoom (maximum 4x lossless zoom)
Maximum photo size	8192×6144（4:3） 4096×3072（4:3） 3840×2160（16:9）	4000×3000
Photo format	JPG (default) / RAW / JPG+RAW	JPG/DNG
Photo shooting mode	Single shooting (default)/Brust shooting/AEB continuous shooting/time lapse/HDR shooting	/
Video resolution	3840×2160 P60/P50/P48/P30(Default)/P25/P24 2720×1528 P60/P50/P48/P30/P25/P24 1920×1080 P120/P60/P50/P48/P30/P25/P24	3840×2160 P30 Night Mode：3840×2160 P30
Video format	MP4 / MOV (MPEG-4 AVC/H.264, HEVC/H.265)	MP4
Video maximum bit rate	60Mbps	/
Support file system	FAT32/exFAT	/

Both visible cameras support 4K photo and 4K video recording. The biggest difference lies in the sensor size, focal length, and aperture. The 640T series visible camera 1 is currently discontinued; the 640T series visible camera 2 version will be shipped instead.

How should we view the Autel EVO II Dual 640T Enterprise V3 drone?

The Autel EVO II Dual 640T Enterprise V3 supports both a 4K visible camera and a 640*512 thermal imaging camera, offering balanced performance and outstanding thermal imaging quality. It can be fully utilized for infrared thermal imaging and visible light inspection, giving it a very clear and strong competitive advantage in the industry market.

Is the Autel EVO II Dual 640T Enterprise the same as the Autel EVO II Dual 640T RTK visual camera?

Yes, the two gimbal cameras have identical specifications.
